Send InquiryUNS S32205 Pipes
MOQ : 50 Kilograms
UNS S32205 Pipes Specification
- Thread Type
- NPT, BSPT (optional)
- Bend Radius
- As per pipe size and specification
- Connection Type
- Welded, Seamless, Threaded
- Yield Strength
- 450 MPa
- Temperature Range
- -50C to +300C
- Flexibility
- Rigid
- Tolerance
- 0.5 mm
- Coating Type
- Uncoated / Pickled
- Diameter
- 6 mm 630 mm
- Sealing Type
- Metallic Seal, Threaded Seal
- Tensile Strength
- 620 MPa
- Product Type
- Pipes
- Material
- UNS S32205 Duplex Stainless Steel
- Connection
- Plain End, Beveled End, Threaded
- Shape
- Round
- Standard
- ASTM A789 / ASTM A790
- Surface Treatment
- Pickled, Annealed
- Outer Diameter
- 6 mm 630 mm
- Section Shape
- Circular
- Length
- Up to 12 meters or as required
- Thickness
- 1 mm 50 mm
- Color
- Silver / Metallic
- Usage
- Industrial, Chemical Processing, Oil & Gas, Marine
- Rated Pressure
- Up to 6000 psi
- Material Grade
- UNS S32205 (Duplex 2205)
- Application
- Fluid Transport, Gas Handling, Structural Use, Heat Exchangers
- Hardness
- Max 290 HB
- Manufacturing Process
- Hot Rolled / Cold Drawn
- End Finish
- Plain, Beveled, or Threaded
- Weldability
- Good, suitable for all standard welding methods
- Hydrostatic Test Pressure
- As per standard requirements
- Surface Finish
- Smooth / Descaled / Polished (optional)
- Density
- 7.8 g/cm³
- Impact Toughness
- High (even at sub-zero temperatures)
- Corrosion Resistance
- Excellent resistance to pitting, crevice, and general corrosion
- Magnetic Properties
- Magnetic (Ferritic-Austenitic Structure)
UNS S32205 Pipes Trade Information
- Minimum Order Quantity
- 50 Kilograms
- Supply Ability
- 50 Kilograms Per Week
- Delivery Time
- 1-2 Week
About UNS S32205 Pipes
Product details
- Specifications : ASTM A790, A789, A928 / ASME SA790, SA789, SA928
- Dimensions : ASTM, ASME, and API
- Size : 1/2NB TO 12 NB IN
- Specialized in : Large Diameter Size
- Schedule : SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, SCH 80S, SCH60, SCH80, SCH120, SCH140, SCH160, SCH XXS, SCH XS
- Type : Seamless / ERW / Welded / Fabricated
- Form : Seamless Pipes, ERW Pipe, EFW, Pipe, Seamless Tube, ERW Tube, Square Pipe.
- Length : Single Random, Double Random & Required Length.
- End : Plain End, Beveled End, Treaded
Superior Corrosion Resistance
UNS S32205 Duplex Stainless Steel Pipes deliver excellent resistance to pitting, crevice, and general corrosion, making them perfectly suited for aggressive and marine environments. Their robust ferritic-austenitic microstructure provides longevity in chemical processing, oil & gas, and marine industries, ensuring extended service life and minimal maintenance costs.
Versatile Manufacturing and Specifications
Available in hot rolled or cold drawn finishes and a variety of surface treatments-including pickled, annealed, or polished-these pipes are manufactured to suit diverse industry requirements. They meet strict tolerances and standards like ASTM A789/A790, with outer diameters ranging from 6 mm to 630 mm and thicknesses from 1 mm to 50 mm. Customized lengths up to 12 meters ensure project flexibility.
FAQ's of UNS S32205 Pipes:
Q: How does UNS S32205 Duplex Stainless Steel pipe provide excellent corrosion resistance?
A: UNS S32205 Duplex Stainless Steel Pipes possess a balanced chromium, molybdenum, and nitrogen content that offers outstanding resistance to pitting, crevice, and general corrosion. This makes them ideal for environments with harsh chemicals, seawater, or chloride exposure, ensuring greater durability and longer service life.Q: What manufacturing processes are used for UNS S32205 pipes?
A: These pipes are produced through hot rolled and cold drawn processes, ensuring precise dimensions and structural integrity. The surfaces can be pickled, annealed, descaled, or optionally polished, catering to different industry requirements.Q: When is it best to use UNS S32205 pipes in industrial applications?
A: UNS S32205 pipes are particularly suitable for use when high strength and corrosion resistance are required. Applications include fluid transport, heat exchangers, marine fittings, oil & gas handling, and structural components in both low-temperature and high-pressure environments.Q: Where can these duplex pipes be supplied or sourced from in India?
A: UNS S32205 Duplex Pipes are available from a range of distributors, exporters, fabricators, manufacturers, suppliers, and wholesalers across India. Many provide customized pipe dimensions, coatings, and surface finishes to suit specific industrial needs.Q: What are the benefits of choosing welded or seamless UNS S32205 pipes?
A: Welded pipes offer cost-effectiveness and suitability for non-critical applications, while seamless pipes provide enhanced strength, uniformity, and superior performance in high-pressure or critical environments. Both types retain the excellent mechanical and corrosion-resistant properties inherent to duplex stainless steels.Q: How does the material's toughness behave at sub-zero temperatures?
A: UNS S32205 pipes exhibit high impact toughness even at temperatures as low as -50C. This characteristic makes them suitable for cryogenic services and environments where cold impact resistance is essential.
